Product introduction
A fluidized bed reactor is a device that fluidizes solid particles in a gas stream and undergoes a reaction. It is widely used in research on processes such as catalytic reactions and fuel conversion.
Product advantages
Precise Control
Equipped with a multi-channel pressure and temperature monitoring system, it achieves a control accuracy of ±0.5%, ensuring stable reaction conditions.
Safety Protection
Equipped with a safety valve and alarm, it automatically shuts off the gas supply in the event of overpressure to prevent accidents.
Corrosion-Resistant Materials
Using 304L stainless steel and fluororubber seals, it offers long-term resistance to corrosion from acids, alkalis, and organic solvents.
Efficient Heat Transfer
Using a double-jacketed insulation structure and equipped with high-thermal conductivity metal pipes, it returns to the set temperature within 10 seconds.
Product Specifications
Size: Non-standard design
Weight: Non-standard design
Power: AC 220V, 50/60Hz
Operational Environment: 0-50°C, 5%-95% RH
System Configuration Module
Process Module: Feed, separation, transfer, reaction, and regeneration.
Reactor Structure: Cylindrical bottom cone made of stainless steel.
Gas Distribution System: Bend type, reduction type, concentric circular cone, flower aspersed, and guide plate structures.
Heat Exchange Unit: Single-tube and tube-bundle ring type heat exchangers.
Gas-Solid Separation Unit: Cyclone separator and bag-type dust collector.
Feed & Transfer System: Gravity flow, mechanical transmission, and pneumatic conveying.
Pressure & Flow Monitoring: Wind pressure tubes measuring inlet and outlet pressures.
Sampling & Analysis Interface: Bypass shunt interface with GC connection and gas analysis capability.
Material Transfer: Riser-based air transfer system for solid movement.
Pneumatic Valve: Air-driven valve with L- or U-shaped structure.
Gas Stream: Forward air blower for stable gas flow.
Automation Control: PLC-based control system for velocity and preheating temperature.
Installation: Integrated device with supporting frame and lifting mechanism.
FAQ
Q: How effective is gas-solid separation?
A: Equipped with a cyclone separator and bag filter system, the separation efficiency can reach over 99.5%.
Q: Does the equipment support continuous operation?
A: It supports long-term continuous operation, with stable operation for over 1,000 hours.
Q: Can the reactor be customized to meet customer needs?
A: We support full customization, including volume, gas connections, heating methods, and automated controls.
Q: How long does the customization process take?
A: Standard equipment is approximately 15–20 business days, while customized equipment is approximately 30–45 business days.
Q: How is the price calculated?
A: We provide a customized quote based on specifications, configuration, and features, along with a detailed price list.
